Forging mould cleaning equipment by Automatic spray graphite
Keyword：
Automatic spray graphite machine
Having been deeply involved in the forging industry for many years, Litai Technology is committed to providing full process supply chain services for forging enterprises, including supporting equipment supply chain, strategic planning of automated production lines
Tel：
- DESCRIPTION
- PARAMETERS
-
- Commodity name: Forging mould cleaning equipment by Automatic spray graphite
The Automatic spray graphite machine, based on the storage of release agents and the supply to automatic lubrication equipment, is a device designed with stainless steel plates. It separates lubrication and cleaning to achieve automatic lubrication and automatic mixing of cleaning fluids. It is also equipped with pressure sensors that can monitor pressure changes in real-time and respond accordingly. Additionally, it supports various functions such as self-cleaning and automatic washing. In conclusion, the Graphite Workstation is a comprehensive and efficient solution for lubrication and cleaning needs in industrial applications.
The Automatic lubrication equipment，Reducing the stickiness of the mold makes it easier for the product to be released from the mold. Serving to control the stroke, it is used for forging and mold release. Before forging, three spraying operations will be carried out: first spraying air, then spraying mold release agent, and finally spraying air again. The automatic lubrication equipment has a delicate and compact appearance, saving space, and adopts servo automatic lubrication.
Automatic spray graphite machine
1. Centrally controlled release agent storage.
2. Comes with a pressurized tank, which has good atomization effect of the release agent.
3. Large jet volume, effectively removes residual oxide scale on the mold surface, and sprays the release agent evenly.
4.Effectively control the spray amount and evenly spray the release agent
Automatic lubrication equipment
1, nozzle atomization, simulate product copying design, spray uniform
2, can control the mold local spraying spray amount, the product better film removal
3, high efficiency, 2S to achieve a full set of actions
4, automatic cleaning nozzle and line, prolong the service life
5, can effectively save installation space, easy maintenance
6, more convenient for customers to replace the mold, repair the press, etc
-
General term Name Name Model Graphite box Clean water tank Installation space Air supply interface Reserve water pipe joint Air compressor exhaust volume Pressure vessel Reserved load switch Rack handling Stirring form Air curtain Overall color matching Function customization Graphite machine ① Graphite workstation Single press-single station LT-SMZ-1-1 1 Simple 1000mm*1000mm*800mm DN25/DN32 6 points external teeth 1.5m³/min or more 0.3m³ or more ≥D25 Painting/spraying Pneumatic motor mixing/pneumatic Optional 1-way/2-way Customer provides color number Customized control methods Single press-double station LT-SMZ-1-2 1 or 2 Integrated water tank 1500mm*1500mm*1200mm DN25/DN32 6 points external teeth 1.5m³/min or more 0.3m³ or more ≥D32 Painting/spraying Pneumatic motor mixing/pneumatic Optional 1-way/2-way Customer provides color number Customized control methods Double press-single station LT-SMZ-2-1 1 or 2 Integrated water tank 1500mm*1500mm*1200mm DN25/DN32 6 points external teeth 1.5m³/min or more 0.3m³ or more ≥D32 Painting/spraying Pneumatic motor mixing/pneumatic Optional 1-way/2-way Customer provides color number Customized control methods Double press - double station LT-SMZ-2-2 At least 2 Integrated water tank 1600mm*1600mm*1200mm DN25/DN32 6 points external teeth 1.5m³/min or more 0.3m³ or more ≥D32 Painting/spraying Pneumatic motor mixing/pneumatic Optional 1-way/2-way Customer provides color number Customized control methods Name Name Model Power options beat Coverage Installation method Installation location Installation space Installation height Upper-lower mold distance Left-right guide post distance Lower mold-ground distance Dimensions Appearance treatment Drive mode Jet form Moving stroke ② Inkjet device Single press-single station LT-SMP-1-1 Slider/screw 2-4 seconds ф50-150mm customized Side shift/side reversal Behind the press 2000mm*2000mm Customer provided Customer provided Customer provided Customer provided Customer provided Painting/spraying Servo motor 1-3 injections can be customized 600-1000mm Single press-double station LT-SMP-1-2 Slider/screw 2-4 seconds ф50-150mm customized Side shift/side reversal Behind the press 2000mm*2000mm Customer provided Customer provided Customer provided Customer provided Customer provided Painting/spraying Servo motor 1-3 sprays can be customized/simultaneous spray/cross spray 600-1000mm Double press-single station LT-SMP-2-1 Slider/screw 2-4 seconds ф50-150mm customized Side shift/side reversal Behind the press 2000mm*2000mm Customer provided Customer provided Customer provided Customer provided Customer provided Painting/spraying Servo motor 1-3 injections can be customized 600-1000mm Double press - double station LT-SMP-2-2 Slider/screw 2-4 seconds ф50-150mm customized Side shift/side reversal Behind the press 2000mm*2000mm Customer provided Customer provided Customer provided Customer provided Customer provided Painting/spraying Servo motor 1-3 sprays can be customized/simultaneous spray/cross spray 600-1000mm
